Skid Steer Loader
KC480
Compact skid-steer loaders feature a small, agile design that allows for easy maneuvering in tight spaces. Compatible with a wide range of attachments—enabling tasks such as loading, sweeping, and breaking—they are widely used in landscaping, interior renovations, site cleanup, and farm operations. Both electric and internal combustion models are available, with customization options offered.
Rated Load :

250KG

Bucket Capacity :

0.1m³

Engine and Power :

Koop 15 kW / Rato 19.2 kW / B&S 17 kW

Call Us

+8619323138308

Product Manual

Get A Quote

Download product Manual

Please leave your information below to obtain more product information

Get A Quote

Characteristic

  • Simple operation, convenient forwarding.

    It is easy to learn and operate, with a moderate overall weight; it can be transported over long distances by trailer and offers flexible relocation between sites.

  • 360° zero-turn capability

    The skid-steer structure enables on-the-spot turning without requiring extra space for turns, offering exceptional flexibility for edge cleaning and material transfer in confined areas.

  • Compact body

    The machine features a compact design, making it suitable for operations in areas inaccessible to large machinery, such as basements, indoor renovation sites, garden landscaping projects, greenhouses, and narrow passageways.

  • High quality walking motor

    The power output is robust and smooth, providing ample torque for loaded travel and powerful starting performance; the system is impact-resistant and has a low failure rate, ensuring reliable, continuous operation over long periods.

  • Rear-hinged engine compartment

    The engine compartment can be tilted backward, providing a clear view of the engine and hydraulic lines; there is ample space for routine maintenance and troubleshooting, facilitating easy upkeep and significantly reducing repair time.

  • High-stability triangular rubber tracks

    Triangular track configuration offers a large ground contact area and excellent shock absorption; the rubber tracks do not damage paving tiles, asphalt surfaces, or lawns, making the machine suitable for both indoor and outdoor use.

Parameter

Overall Dimensions        2535*1150*1300mmRated Pressure  16Mpa
Operating Weight1305kgBucket Width             1150mm
Gradeability25°Ground Clearance       220mm
Max. Breakout Force   4.5KNUnloading Distance580mm
Rated Load250kgTrack Ground Contact Length1330mm
Max. Load350kgOverall Length with Bucket2535mm
Travel Speed      0-5km/hTrack Model180*72*45
Machine Width1089mmCylinders2
